Our Rotary Dryer is designed to deliver exceptional performance, durability, and precision. With advanced technology and robust engineering, this machine is the ultimate choice for achieving superior drying results and maximizing productivity.
Shell Cubage
Capacity
Installation Obliquity
| 规格Spec ./m (直径×长度) (Dia. ×Length) |
筒体容积 Shell Cubage (m²) |
生产能力 Capacity (t/h) |
安装斜度 Installation Obliquity (%) |
最高进气温度 Highest Inlet Air Temperature (℃) |
主电动机 Main Motor (kw) |
总重量 Weight (1) |
| φ1.2×8.0 | 9 | 1.9~2.4 | 3~5 | 700~800 | 7.5 | 9 |
| φ1.2×10 | 11.3 | 2.4~3.0 | 3~5 | 700~800 | 7.5 | 11 |
| φ1.5×12 | 21.2 | 4.5~5.7 | 3~5 | 700~800 | 15 | 18.5 |
| φ1.5×14 | 24.7 | 5.3~6.6 | 3~5 | 700~800 | 15 | 19.7 |
| φ1.5×15 | 26.5 | 5.7~7.1 | 3~5 | 700~800 | 15 | 20.5 |
| φ1.8×12 | 30.5 | 6.5~8.1 | 3~5 | 700~800 | 18.5 | 21.5 |
| φ1.8×14 | 35.6 | 7.6~9.5 | 3~5 | 700~800 | 18.5 | 23 |
| φ2.2×12 | 45.6 | 9.7~12.2 | 3~5 | 700~800 | 22 | 33.5 |
| φ2.2×14 | 53.2 | 11.4~14.2 | 3~5 | 700~800 | 22 | 36 |
| φ2.2×16 | 60.8 | 13.0~16.2 | 3~5 | 700~800 | 22 | 38 |
| φ2.4×14 | 63.3 | 13.5~16.9 | 3~5 | 700~800 | 37 | 45 |
| φ2.4×18 | 81.4 | 17.4~21.7 | 3~5 | 700~800 | 37 | 49 |
| φ2.4×20 | 90.4 | 19.3~24.1 | 3~5 | 700~800 | 45 | 54 |
| φ2.4×22 | 99.5 | 21.2~26.5 | 3~5 | 700~800 | 45 | 58 |
| φ2.6×24 | 127.4 | 27.2~34.0 | 3~5 | 700~800 | 55 | 73 |
| φ3.0×20 | 141.3 | 30.1~37.7 | 3~5 | 700~800 | 75 | 85 |
| φ3.0×25 | 176.6 | 37.7~47.1 | 3~5 | 700~800 | 75 | 95 |
| φ3.2×25 | 201 | 42.9~53.6 | 3~5 | 700~800 | 90 | 110 |
| φ3.6×28 | 285 | 60.8~76.0 | 3~5 | 700~800 | 160 | 135 |
Are you looking for a reliable, efficient, and cost-effective solution for drying bulk materials in your mining, agriculture, or industrial operations? Our Rotary Dryer is designed to deliver exceptional performance, durability, and precision. With advanced technology and robust engineering, this machine is the ultimate choice for achieving superior drying results and maximizing productivity.
Why Choose Our Rotary Dryer?
Superior Drying Efficiency:
Our rotary dryer ensures uniform and efficient drying of materials, delivering consistent moisture content and quality.
Versatility for Multiple Applications:
Ideal for drying materials like sand, coal, minerals, grains, and more, our rotary dryer adapts to a wide range of industries and applications.
Durable and Reliable Design:
Built with high-quality materials and heavy-duty components, our rotary dryer is designed to withstand harsh operating conditions, ensuring long-lasting performance.
Low Maintenance and Operational Costs:
With a simple design and minimal moving parts, maintenance is quick and hassle-free, reducing downtime and saving you money.
Energy-Efficient Operation:
Our rotary dryer is optimized for low energy consumption, helping you reduce operational costs while maintaining high efficiency.
Customizable Solutions:
We offer tailored configurations, including size, capacity, and temperature adjustments, to meet your specific drying needs, ensuring the perfect fit for your operations.
Safe and Smooth Operation:
Equipped with safety features like emergency stop buttons and protective guards, our rotary dryer ensures a safe working environment for operators.
